Maintained type : MP016S/F11Z-EDY (LED 전압과 색상 선택)

Momentary type : MP016S/F11-EDY (LED 전압과 색상 선택)

• LED COLOR 종류 : RED, GREEN, BLUE, YELLOW, ORANGE, WHITE.

• Operating Temperature : -25 ~ 55도

• Storage Temperature : -40 ~ 70도

• Operating Humidity : 10% ~ 99%

• Input voltage : 3 ~ 250 VDC/AC

• Incoming Current : < 5A

• Contact Resistance : <50mΩ

• Insulation Resistance : >100mΩ 500VDC

• Dielectric Strength : >2000VAC 1Min

• Pulse Duration : <50Ms

• Operating Pressure : 3~6N

• Waterproof Level : IP67 IK10

• Operating Life : >1000000 times, LED > 50000h

• Material : Stainless steel Aluminum, Copper plating)

• Terminal type : Solder terminal
